[Staple]
Overview
Set the number of staples for Fold & Staple.
NOTICE
- The folded and stapled sheets are output to the Conveyance belt. Set the Delivery tray extension (tray) as preparation, and open the Stopper. Otherwise, the printed paper may drop down from the Conveyance belt. Also, the full-load detection function of Saddle Stitcher SD-513 may not work.
- When using easy-to-curl and thin paper for Fold & Staple, output prints so that paper is curled inside. Before printing a booklet, print only several sheets to the Secondary (sub) tray, and check the curl orientation. If the printed-out sheets are curled upward, paper is curled inward when a booklet is created.
Tips
- [Valid Object] cannot be changed in [All Sheets] because it is fixed.
Reference
- For details about Fold & Staple, refer to What Is the [Fold&Staple]?.
Specifications
Category | Print Workflow, Copy / Scan | ||
Location | Machine | Touch Panel | |
Printer driver | - | ||
Application | - | ||
Required options | Saddle Stitcher SD-513 | ||
Required items | - | ||
Setting items | [2 Positions] | Staples at 2 positions. | |
[4 Positions] | Staples at 4 positions. | ||
Remarks | - | ||
Reference | - | ||
Screen access | Touch panel - [MACHINE] - [JOB LIST] - [Hold Job] - [Job Ticket] - [Job Ticket Edit] - [Fold & Staple] | ||
Touch panel - [MACHINE] - [JOB LIST] - [Hold Job] - [Page Edit] - [Job Ticket Edit] - [Fold & Staple] | |||
